Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 865
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (ddrc) mode_sts_reg
Register mode_sts_reg Details
reg_phy_rdc_we_to_re
_delay
11:8 rw 0x2 This register value + 1 give the number of clock
cycles between writing into the Read Capture
FIFO and the read operation.
The setting of this register determines the read
data timing and depends upon total delay in the
system for read operation which include fly-by
delays, trace delay, clkout_invert etc.
This is used only if reg_phy_use_fixed_re=1.
reg_phy_wr_cmd_to_d
ata
7:4 rw 0x0 Not used in DFI PHY.
reg_phy_rd_cmd_to_d
ata
3:0 rw 0x0 Not used in DFI PHY.
Name mode_sts_reg
Relative Address 0x00000054
Absolute Address 0xF8006054
Width 21 bits
Access Type ro
Reset Value 0x00000000
Description Controller operation mode status
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
ddrc_reg_dbg_hpr_q_d
epth
20:16 ro 0x0 Indicates the number of entries currently in the
High Priority Read (HPR) CAM.
ddrc_reg_dbg_lpr_q_d
epth
15:10 ro 0x0 Indicates the number of entries currently in the
Low Priority Read (LPR) CAM.
ddrc_reg_dbg_wr_q_d
epth
9:4 ro 0x0 Indicates the number of entries currently in the
Write CAM.
ddrc_reg_dbg_stall 3 ro 0x0 0: commands are being accepted.
1: no commands are accepted by the controller.
ddrc_reg_operating_m
ode
2:0 ro 0x0 Gives the status of the controller.
0: DDRC Init
1: Normal operation
2: Powerdown mode
3: Self-refresh mode
4 and above: deep power down mode (LPDDR2
only)
