Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 903
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (ddrc) axi_priority_wr_port0
Note: This register is the first in an array of 4 identical registers listed in the table below. The details
provided in this section apply to the entire array.
Register axi_priority_wr_port0 to axi_priority_wr_port3 Details
Name axi_priority_wr_port0
Relative Address 0x00000208
Absolute Address 0xF8006208
Width 20 bits
Access Type mixed
Reset Value 0x000803FF
Description AXI Priority control for write port 0.
Name Address
axi_priority_wr_port0 0xf8006208
axi_priority_wr_port1 0xf800620c
axi_priority_wr_port2 0xf8006210
axi_priority_wr_port3 0xf8006214
Field Name Bits Type Reset Value Description
reserved 19 rw 0x1 Reserved. Do not modify.
reg_arb_dis_page_mat
ch_wr_portn
18 rw 0x0 Disable the page match feature.
reg_arb_disable_urgen
t_wr_portn
17 rw 0x0 Disable urgent for this Write Port.
reg_arb_disable_aging
_wr_portn
16 rw 0x0 Disable aging for this Write Port.
reserved 15:10 ro 0x0 Reserved
reg_arb_pri_wr_portn 9:0 rw 0x3FF Priority of this Write Port n. Value in this register
used to load the aging counters (when respective
port request is asserted and grant is generated to
that port). These register can be reprogrammed to
set priority of each port. Lower the value more
will be priority given to the port. For example if
0x82 (port 0) value is set to 'h3FF, and 0x83 (port
1) is set to 'h0FF, and both port0 and port1 have
requests, in this case port1 will get high priority
and grant will be given to port1. Note that the
minimum write priority should be set to 0x4.
