Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 904
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (ddrc) axi_priority_rd_port0
Note: This register is the first in an array of 4 identical registers listed in the table below. The details
provided in this section apply to the entire array.
Register axi_priority_rd_port0 to axi_priority_rd_port3 Details
Name axi_priority_rd_port0
Relative Address 0x00000218
Absolute Address 0xF8006218
Width 20 bits
Access Type mixed
Reset Value 0x000003FF
Description AXI Priority control for read port 0.
Name Address
axi_priority_rd_port0 0xf8006218
axi_priority_rd_port1 0xf800621c
axi_priority_rd_port2 0xf8006220
axi_priority_rd_port3 0xf8006224
Field Name Bits Type Reset Value Description
reg_arb_set_hpr_rd_po
rtn
19 rw 0x0 Enable reads to be generated as HPR for this Read
Port.
reg_arb_dis_page_mat
ch_rd_portn
18 rw 0x0 Disable the page match feature.
reg_arb_disable_urgen
t_rd_portn
17 rw 0x0 Disable urgent for this Read Port.
reg_arb_disable_aging
_rd_portn
16 rw 0x0 Disable aging for this Read Port.
reserved 15:10 ro 0x0 Reserved. Do not modify.
reg_arb_pri_rd_portn 9:0 rw 0x3FF Priority of this Read Port n. Value in this register
used to load the aging counters (when respective
port request is asserted and grant is generated to
that port). These register can be reprogrammed to
set priority of each port. Lower the value more
will be priority given to the port. For example if
0x82 (port 0) value is set to 'h3FF, and 0x83 (port
1) is set to 'h0FF, and both port0 and port1 have
requests, in this case port1 will get high priority
and grant will be given to port1.
