Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 905
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (ddrc) excl_access_cfg0
Note: This register is the first in an array of 4 identical registers listed in the table below. The details
provided in this section apply to the entire array.
Register excl_access_cfg0 to excl_access_cfg3 Details
Register (ddrc) mode_reg_read
Register mode_reg_read Details
This registers is applicable only when LPDDR2 is selected.
Name excl_access_cfg0
Relative Address 0x00000294
Absolute Address 0xF8006294
Width 18 bits
Access Type rw
Reset Value 0x00000000
Description Exclusive access configuration for port 0.
Name Address
excl_access_cfg0 0xf8006294
excl_access_cfg1 0xf8006298
excl_access_cfg2 0xf800629c
excl_access_cfg3 0xf80062a0
Field Name Bits Type Reset Value Description
reg_excl_acc_id1_port 17:9 rw 0x0 Reserved
reg_excl_acc_id0_port 8:0 rw 0x0 Reserved
Name mode_reg_read
Relative Address 0x000002A4
Absolute Address 0xF80062A4
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Mode register read data
