Appendix B: Register Details
Register lpddr_ctrl3 Details
Reset Value 0x00000601
Description LPDDR2 Control 3
Field Name Bits Type Reset Value Description
reg_ddrc_dev_zqinit_x
32
17:8 rw 0x6 ZQ initial calibration, tZQINIT.
Units: 32 clock cycles. LPDDR2 typically requires
1 us.
reg_ddrc_max_auto_in
it_x1024
7:0 rw 0x1 Maximum duration of the auto initialization,
tINIT5.
Units: 1024 clock cycles. LPDDR2 typically
requires 10 us.
