Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 909
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
B.7 CoreSight Cross Trigger Interface (cti)
Register Summary
Module Name CoreSight Cross Trigger Interface (cti)
Base Address 0xF8898000 debug_cpu_cti0
0xF8899000 debug_cpu_cti1
0xF8802000 debug_cti_etb_tpiu
0xF8809000 debug_cti_ftm
Description Cross Trigger Interface
Vendor Info
Register Name Address Width Type Reset Value Description
CTICONTROL
0x00000000 1 rw 0x00000000 CTI Control Register
CTIINTACK
0x00000010 8 wo 0x00000000 CTI Interrupt Acknowledge
Register
CTIAPPSET
0x00000014 4 rw 0x00000000 CTI Application Trigger Set
Register
CTIAPPCLEAR
0x00000018 4 wo 0x00000000 CTI Application Trigger Clear
Register
CTIAPPPULSE
0x0000001C 4 wo 0x00000000 CTI Application Pulse Register
CTIINEN0
0x00000020 4 rw 0x00000000 CTI Trigger to Channel Enable 0
Register
CTIINEN1
0x00000024 4 rw 0x00000000 CTI Trigger to Channel Enable 1
Register
CTIINEN2
0x00000028 4 rw 0x00000000 CTI Trigger to Channel Enable 2
Register
CTIINEN3
0x0000002C 4 rw 0x00000000 CTI Trigger to Channel Enable 3
Register
CTIINEN4
0x00000030 4 rw 0x00000000 CTI Trigger to Channel Enable 4
Register
CTIINEN5
0x00000034 4 rw 0x00000000 CTI Trigger to Channel Enable 5
Register
CTIINEN6
0x00000038 4 rw 0x00000000 CTI Trigger to Channel Enable 6
Register
CTIINEN7
0x0000003C 4 rw 0x00000000 CTI Trigger to Channel Enable 7
Register
CTIOUTEN0
0x000000A0 4 rw 0x00000000 CTI Channel to Trigger Enable 0
Register
