Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 911
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (cti) CTICONTROL
Register CTICONTROL Details
Register (cti) CTIINTACK
DTIR 0x00000FCC 8 ro 0x00000014 Device Type Identifier Register
PERIPHID4
0x00000FD0 8 ro 0x00000004 Peripheral ID4
PERIPHID5
0x00000FD4 8 ro 0x00000000 Peripheral ID5
PERIPHID6
0x00000FD8 8 ro 0x00000000 Peripheral ID6
PERIPHID7
0x00000FDC 8 ro 0x00000000 Peripheral ID7
PERIPHID0
0x00000FE0 8 ro 0x00000006 Peripheral ID0
PERIPHID1
0x00000FE4 8 ro 0x000000B9 Peripheral ID1
PERIPHID2
0x00000FE8 8 ro 0x0000002B Peripheral ID2
PERIPHID3
0x00000FEC 8 ro 0x00000000 Peripheral ID3
COMPID0
0x00000FF0 8 ro 0x0000000D Component ID0
COMPID1
0x00000FF4 8 ro 0x00000090 Component ID1
COMPID2
0x00000FF8 8 ro 0x00000005 Component ID2
COMPID3
0x00000FFC 8 ro 0x000000B1 Component ID3
Name CTICONTROL
Relative Address 0x00000000
Absolute Address debug_cpu_cti0: 0xF8898000
debug_cpu_cti1: 0xF8899000
debug_cti_etb_tpiu: 0xF8802000
debug_cti_ftm: 0xF8809000
Width 1 bits
Access Type rw
Reset Value 0x00000000
Description CTI Control Register
Register Name Address Width Type Reset Value Description
Field Name Bits Type Reset Value Description
GLBEN 0 rw 0x0 Enables or disables the ECT. When disabled, all
cross triggering mapping logic functionality is
disabled for this processor.
Name CTIINTACK
