Appendix B: Register Details
Register CTIINTACK Details
Register (cti) CTIAPPSET
Relative Address 0x00000010
Absolute Address debug_cpu_cti0: 0xF8898010
debug_cpu_cti1: 0xF8899010
debug_cti_etb_tpiu: 0xF8802010
debug_cti_ftm: 0xF8809010
Width 8 bits
Access Type wo
Reset Value 0x00000000
Description CTI Interrupt Acknowledge Register
Field Name Bits Type Reset Value Description
INTACK 7:0 wo 0x0 Acknowledges the corresponding CTITRIGOUT
output:
1 = CTITRIGOUT is acknowledged and is cleared
when MAPTRIGOUT is LOW.
0 = no effect
There is one bit of the register for each
CTITRIGOUT output.
Name CTIAPPSET
Relative Address 0x00000014
Absolute Address debug_cpu_cti0: 0xF8898014
debug_cpu_cti1: 0xF8899014
debug_cti_etb_tpiu: 0xF8802014
debug_cti_ftm: 0xF8809014
Width 4 bits
Access Type rw
Reset Value 0x00000000
Description CTI Application Trigger Set Register
