Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 913
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register CTIAPPSET Details
Register (cti) CTIAPPCLEAR
Register CTIAPPCLEAR Details
Register (cti) CTIAPPPULSE
Field Name Bits Type Reset Value Description
APPSET 3:0 rw 0x0 Setting a bit HIGH generates a channel event for
the selected channel.
Read:
0 = application trigger inactive (reset)
1 = application trigger active.
Write:
0 = no effect
1 = generate channel event.
There is one bit of the register for each channel.
Name CTIAPPCLEAR
Relative Address 0x00000018
Absolute Address debug_cpu_cti0: 0xF8898018
debug_cpu_cti1: 0xF8899018
debug_cti_etb_tpiu: 0xF8802018
debug_cti_ftm: 0xF8809018
Width 4 bits
Access Type wo
Reset Value 0x00000000
Description CTI Application Trigger Clear Register
Field Name Bits Type Reset Value Description
APPCLEAR 3:0 wo 0x0 Clears corresponding bits in the CTIAPPSET
register.
1 = application trigger disabled in the CTIAPPSET
register
0 = no effect.
There is one bit of the register for each channel.
Name CTIAPPPULSE
Relative Address 0x0000001C
