Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 914
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register CTIAPPPULSE Details
Register (cti) CTIINEN0
Absolute Address debug_cpu_cti0: 0xF889801C
debug_cpu_cti1: 0xF889901C
debug_cti_etb_tpiu: 0xF880201C
debug_cti_ftm: 0xF880901C
Width 4 bits
Access Type wo
Reset Value 0x00000000
Description CTI Application Pulse Register
Field Name Bits Type Reset Value Description
APPULSE 3:0 wo 0x0 Setting a bit HIGH generates a channel event
pulse for the selected channel.
Write:
1 = channel event pulse generated for one
CTICLK period
0 = no effect.
There is one bit of the register for each channel.
Name CTIINEN0
Relative Address 0x00000020
Absolute Address debug_cpu_cti0: 0xF8898020
debug_cpu_cti1: 0xF8899020
debug_cti_etb_tpiu: 0xF8802020
debug_cti_ftm: 0xF8809020
Width 4 bits
Access Type rw
Reset Value 0x00000000
Description CTI Trigger to Channel Enable 0 Register
