Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 924
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (cti) CTIOUTEN6
Register CTIOUTEN6 Details
Register (cti) CTIOUTEN7
Name CTIOUTEN6
Relative Address 0x000000B8
Absolute Address debug_cpu_cti0: 0xF88980B8
debug_cpu_cti1: 0xF88990B8
debug_cti_etb_tpiu: 0xF88020B8
debug_cti_ftm: 0xF88090B8
Width 4 bits
Access Type rw
Reset Value 0x00000000
Description CTI Channel to Trigger Enable 6 Register
Field Name Bits Type Reset Value Description
TRIGOUTEN 3:0 rw 0x0 Changing the value of this bit from a 0 to a 1
enables a channel event for the corresponding
channel to generate an CTITRIGOUT output:
0 = the channel input (CTICHIN) from the CTM is
not routed to the CTITRIGOUT output
1 = the channel input (CTICHIN) from the CTM is
routed to the CTITRIGOUT output.
There is one bit for each of the four channels. For
example in register CTIOUTEN0, enabling
bit 0 enables CTICHIN[0] to cause a trigger event
on the CTITRIGOUT[0] output.
Name CTIOUTEN7
Relative Address 0x000000BC
Absolute Address debug_cpu_cti0: 0xF88980BC
debug_cpu_cti1: 0xF88990BC
debug_cti_etb_tpiu: 0xF88020BC
debug_cti_ftm: 0xF88090BC
Width 4 bits
Access Type rw
Reset Value 0x00000000
Description CTI Channel to Trigger Enable 7 Register
