Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 926
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register CTITRIGOUTSTATUS Details
Register (cti) CTICHINSTATUS
Register CTICHINSTATUS Details
Absolute Address debug_cpu_cti0: 0xF8898134
debug_cpu_cti1: 0xF8899134
debug_cti_etb_tpiu: 0xF8802134
debug_cti_ftm: 0xF8809134
Width 8 bits
Access Type ro
Reset Value 0x00000000
Description CTI Trigger Out Status Register
Field Name Bits Type Reset Value Description
TRIGOUTSTATUS 7:0 ro 0x0 Shows the status of the CTITRIGOUT outputs.
1 = CTITRIGOUT is active
0 = CTITRIGOUT is inactive (reset).
There is one bit of the register for each trigger
output.
Name CTICHINSTATUS
Relative Address 0x00000138
Absolute Address debug_cpu_cti0: 0xF8898138
debug_cpu_cti1: 0xF8899138
debug_cti_etb_tpiu: 0xF8802138
debug_cti_ftm: 0xF8809138
Width 4 bits
Access Type ro
Reset Value x
Description CTI Channel In Status Register
Field Name Bits Type Reset Value Description
CTCHINSTATUS 3:0 ro x Shows the status of the CTICHIN inputs:
1 = CTICHIN is active
0 = CTICHIN is inactive.
Because the register provides a view of the raw
CTICHIN inputs from the CTM, the reset
value is unknown. There is one bit of the register
for each channel input.
