Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 927
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (cti) CTICHOUTSTATUS
Register CTICHOUTSTATUS Details
Register (cti) CTIGATE
Register CTIGATE Details
Name CTICHOUTSTATUS
Relative Address 0x0000013C
Absolute Address debug_cpu_cti0: 0xF889813C
debug_cpu_cti1: 0xF889913C
debug_cti_etb_tpiu: 0xF880213C
debug_cti_ftm: 0xF880913C
Width 4 bits
Access Type ro
Reset Value 0x00000000
Description CTI Channel Out Status Register
Field Name Bits Type Reset Value Description
CTCHOUTSTATUS 3:0 ro 0x0 Shows the status of the CTICHOUT outputs.
1 = CTICHOUT is active
0 = CTICHOUT is inactive (reset).
There is one bit of the register for each channel
output.
Name CTIGATE
Relative Address 0x00000140
Absolute Address debug_cpu_cti0: 0xF8898140
debug_cpu_cti1: 0xF8899140
debug_cti_etb_tpiu: 0xF8802140
debug_cti_ftm: 0xF8809140
Width 4 bits
Access Type rw
Reset Value 0x0000000F
Description Enable CTI Channel Gate Register
Field Name Bits Type Reset Value Description
CTIGATEEN3 3 rw 0x1 Enable CTICHOUT3.
CTIGATEEN2 2 rw 0x1 Enable CTICHOUT2.
