Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 928
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (cti) ASICCTL
Register ASICCTL Details
Register (cti) ITCHINACK
Register ITCHINACK Details
CTIGATEEN1 1 rw 0x1 Enable CTICHOUT1.
CTIGATEEN0 0 rw 0x1 Enable CTICHOUT0.
Name ASICCTL
Relative Address 0x00000144
Absolute Address debug_cpu_cti0: 0xF8898144
debug_cpu_cti1: 0xF8899144
debug_cti_etb_tpiu: 0xF8802144
debug_cti_ftm: 0xF8809144
Width 8 bits
Access Type rw
Reset Value 0x00000000
Description External Multiplexor Control Register
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
ASICCTL 7:0 rw 0x0 Implementation defined ASIC control, value
written to the register is output on ASICCTL[7:0].
Name ITCHINACK
Relative Address 0x00000EDC
Absolute Address debug_cpu_cti0: 0xF8898EDC
debug_cpu_cti1: 0xF8899EDC
debug_cti_etb_tpiu: 0xF8802EDC
debug_cti_ftm: 0xF8809EDC
Width 4 bits
Access Type wo
Reset Value 0x00000000
Description ITCHINACK Register
Field Name Bits Type Reset Value Description
CTCHINACK 3:0 wo 0x0 Set the value of the CTCHINACK outputs
