Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 931
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ITTRIGOUTACK Details
Register (cti) ITCHIN
Register ITCHIN Details
Register (cti) ITTRIGIN
Width 8 bits
Access Type ro
Reset Value 0x00000000
Description ITTRIGOUTACK Register
Field Name Bits Type Reset Value Description
CTTRIGOUTACK 7:0 ro 0x0 Read the values of the CTTRIGOUTACK inputs
Name ITCHIN
Relative Address 0x00000EF4
Absolute Address debug_cpu_cti0: 0xF8898EF4
debug_cpu_cti1: 0xF8899EF4
debug_cti_etb_tpiu: 0xF8802EF4
debug_cti_ftm: 0xF8809EF4
Width 4 bits
Access Type ro
Reset Value 0x00000000
Description ITCHIN Register
Field Name Bits Type Reset Value Description
CTCHIN 3:0 ro 0x0 Read the values of the CTCHIN inputs
Name ITTRIGIN
Relative Address 0x00000EF8
Absolute Address debug_cpu_cti0: 0xF8898EF8
debug_cpu_cti1: 0xF8899EF8
debug_cti_etb_tpiu: 0xF8802EF8
debug_cti_ftm: 0xF8809EF8
Width 8 bits
Access Type ro
Reset Value 0x00000000
