Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 932
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ITTRIGIN Details
Register (cti) ITCTRL
Register ITCTRL Details
Register (cti) CTSR
Description ITTRIGIN Register
Field Name Bits Type Reset Value Description
CTTRIGIN 7:0 ro 0x0 Read the values of the CTTRIGIN inputs
Name ITCTRL
Relative Address 0x00000F00
Absolute Address debug_cpu_cti0: 0xF8898F00
debug_cpu_cti1: 0xF8899F00
debug_cti_etb_tpiu: 0xF8802F00
debug_cti_ftm: 0xF8809F00
Width 1 bits
Access Type rw
Reset Value 0x00000000
Description IT Control Register
Field Name Bits Type Reset Value Description
0 rw 0x0 Enable IT Registers
Name CTSR
Relative Address 0x00000FA0
Absolute Address debug_cpu_cti0: 0xF8898FA0
debug_cpu_cti1: 0xF8899FA0
debug_cti_etb_tpiu: 0xF8802FA0
debug_cti_ftm: 0xF8809FA0
Width 4 bits
Access Type rw
Reset Value 0x0000000F
Description Claim Tag Set Register
