Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 939
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register PERIPHID0 Details
Register (cti) PERIPHID1
Register PERIPHID1 Details
Register (cti) PERIPHID2
Absolute Address debug_cpu_cti0: 0xF8898FE0
debug_cpu_cti1: 0xF8899FE0
debug_cti_etb_tpiu: 0xF8802FE0
debug_cti_ftm: 0xF8809FE0
Width 8 bits
Access Type ro
Reset Value 0x00000006
Description Peripheral ID0
Field Name Bits Type Reset Value Description
7:0 ro 0x6 PartNumber0
Name PERIPHID1
Relative Address 0x00000FE4
Absolute Address debug_cpu_cti0: 0xF8898FE4
debug_cpu_cti1: 0xF8899FE4
debug_cti_etb_tpiu: 0xF8802FE4
debug_cti_ftm: 0xF8809FE4
Width 8 bits
Access Type ro
Reset Value 0x000000B9
Description Peripheral ID1
Field Name Bits Type Reset Value Description
JEP106ID 7:4 ro 0xB JEP106 Identity Code [3:0]
PartNumber1 3:0 ro 0x9 PartNumber1
Name PERIPHID2
Relative Address 0x00000FE8
