Appendix B: Register Details
Register COMPID2 Details
Register (cti) COMPID3
Register COMPID3 Details
Width 8 bits
Access Type ro
Reset Value 0x00000005
Description Component ID2
Field Name Bits Type Reset Value Description
7:0 ro 0x5 Preamble
Name COMPID3
Relative Address 0x00000FFC
Absolute Address debug_cpu_cti0: 0xF8898FFC
debug_cpu_cti1: 0xF8899FFC
debug_cti_etb_tpiu: 0xF8802FFC
debug_cti_ftm: 0xF8809FFC
Width 8 bits
Access Type ro
Reset Value 0x000000B1
Description Component ID3
Field Name Bits Type Reset Value Description
7:0 ro 0xB1 Preamble
