Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 946
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (cortexa9_pmu) PMXEVCNTR5
Register PMXEVCNTR5 Details
Register (cortexa9_pmu) PMCCNTR
Register PMCCNTR Details
Register (cortexa9_pmu) PMXEVTYPER0
Name PMXEVCNTR5
Relative Address 0x00000014
Absolute Address debug_cpu_pmu0: 0xF8891014
debug_cpu_pmu1: 0xF8893014
Width 32 bits
Access Type rw
Reset Value x
Description PMU event counter 5
Field Name Bits Type Reset Value Description
PMXEVCNTR5 31:0 rw x PMU event counter 5
Name PMCCNTR
Relative Address 0x0000007C
Absolute Address debug_cpu_pmu0: 0xF889107C
debug_cpu_pmu1: 0xF889307C
Width 32 bits
Access Type rw
Reset Value x
Description pmccntr
Field Name Bits Type Reset Value Description
PMCCNTR 31:0 rw x pmccntr
Name PMXEVTYPER0
Relative Address 0x00000400
Absolute Address debug_cpu_pmu0: 0xF8891400
debug_cpu_pmu1: 0xF8893400
Width 32 bits
