Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 949
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register PMXEVTYPER5 Details
Register (cortexa9_pmu) PMCNTENSET
Register PMCNTENSET Details
Register (cortexa9_pmu) PMCNTENCLR
Register PMCNTENCLR Details
Access Type rw
Reset Value x
Description pmevtyper5
Field Name Bits Type Reset Value Description
PMXEVTYPER5 31:0 rw x pmevtyper5
Name PMCNTENSET
Relative Address 0x00000C00
Absolute Address debug_cpu_pmu0: 0xF8891C00
debug_cpu_pmu1: 0xF8893C00
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description pmcntenset
Field Name Bits Type Reset Value Description
PMCNTENSET 31:0 rw 0x0 pmcntenset
Name PMCNTENCLR
Relative Address 0x00000C20
Absolute Address debug_cpu_pmu0: 0xF8891C20
debug_cpu_pmu1: 0xF8893C20
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description pmcntenclr
Field Name Bits Type Reset Value Description
PMCNTENCLR 31:0 rw 0x0 pmcntenclr
