Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 951
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register PMOVSR Details
Register (cortexa9_pmu) PMSWINC
Register PMSWINC Details
Register (cortexa9_pmu) PMCR
Register PMCR Details
Access Type rw
Reset Value x
Description pmovsr
Field Name Bits Type Reset Value Description
PMOVSR 31:0 rw x pmovsr
Name PMSWINC
Relative Address 0x00000CA0
Absolute Address debug_cpu_pmu0: 0xF8891CA0
debug_cpu_pmu1: 0xF8893CA0
Width 32 bits
Access Type wo
Reset Value x
Description pmswinc
Field Name Bits Type Reset Value Description
PMSWINC 31:0 wo x pmswinc
Name PMCR
Relative Address 0x00000E04
Absolute Address debug_cpu_pmu0: 0xF8891E04
debug_cpu_pmu1: 0xF8893E04
Width 32 bits
Access Type rw
Reset Value 0x41093000
Description pmcr
Field Name Bits Type Reset Value Description
PMCR 31:0 rw 0x41093000 pmcr
