Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 952
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (cortexa9_pmu) PMUSERENR
Register PMUSERENR Details
Name PMUSERENR
Relative Address 0x00000E08
Absolute Address debug_cpu_pmu0: 0xF8891E08
debug_cpu_pmu1: 0xF8893E08
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description pmuserenr
Field Name Bits Type Reset Value Description
PMUSERENR 31:0 rw 0x0 pmuserenr
This register is read-only in user mode.
