Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 954
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
ETMACTR3 0x00000088 12 mixed 0x00000001 Address Comparator Access
Type Register 3
ETMACTR4
0x0000008C 12 mixed 0x00000001 Address Comparator Access
Type Register 4
ETMACTR5
0x00000090 12 mixed 0x00000001 Address Comparator Access
Type Register 5
ETMACTR6
0x00000094 12 mixed 0x00000001 Address Comparator Access
Type Register 6
ETMACTR7
0x00000098 12 mixed 0x00000001 Address Comparator Access
Type Register 7
ETMACTR8
0x0000009C 12 mixed 0x00000001 Address Comparator Access
Type Register 8
ETMCNTRLDVR1
0x00000140 16 rw 0x00000000 Counter Reload Value Register 1
ETMCNTRLDVR2
0x00000144 16 rw 0x00000000 Counter Reload Value Register 2
ETMCNTENR1
0x00000150 18 mixed 0x00020000 Counter Enable Event Register 1
ETMCNTENR2
0x00000154 18 mixed 0x00020000 Counter Enable Event Register 2
ETMCNTRLDEVR1
0x00000160 17 rw 0x00000000 Counter Reload Event Register 1
ETMCNTRLDEVR2
0x00000164 17 rw 0x00000000 Counter Reload Event Register 2
ETMCNTVR1
0x00000170 16 rw 0x00000000 Counter Value Register 1
ETMCNTVR2
0x00000174 16 rw 0x00000000 Counter Value Register 2
ETMSQ12EVR
0x00000180 17 rw 0x00000000 Sequencer State Transition
Event Register 12
ETMSQ21EVR
0x00000184 17 rw 0x00000000 Sequencer State Transition
Event Register 21
ETMSQ23EVR
0x00000188 17 rw 0x00000000 Sequencer State Transition
Event Register 23
ETMSQ31EVR
0x0000018C 17 rw 0x00000000 Sequencer State Transition
Event Register 31
ETMSQ32EVR
0x00000190 17 rw 0x00000000 Sequencer State Transition
Event Register 32
ETMSQ13EVR
0x00000194 17 rw 0x00000000 Sequencer State Transition
Event Register 13
ETMSQR
0x0000019C 2 rw 0x00000000 Current Sequencer State
Register
ETMEXTOUTEVR1
0x000001A0 17 rw 0x00000000 External Output Event Register
1
ETMEXTOUTEVR2
0x000001A4 17 rw 0x00000000 External Output Event Register
2
ETMCIDCVR1
0x000001B0 32 rw 0x00000000 Context ID Comparator Value
Register
Register Name Address Width Type Reset Value Description
