Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 955
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
ETMCIDCMR 0x000001BC 32 rw 0x00000000 Context ID Comparator Mask
Register
ETMSYNCFR
0x000001E0 12 mixed 0x00000400 Synchronization Frequency
Register
ETMIDR
0x000001E4 32 ro 0x411CF301 ID Register
ETMCCER
0x000001E8 26 ro 0x000008EA Configuration Code Extension
Register
ETMEXTINSELR
0x000001EC 14 rw 0x00000000 Extended External Input
Selection Register
ETMAUXCR
0x000001FC 4 rw 0x00000000 Auxiliary Control Register
ETMTRACEIDR
0x00000200 7 rw 0x00000000 CoreSight Trace ID Register
OSLSR
0x00000304 32 ro 0x00000000 OS Lock Status Register
ETMPDSR
0x00000314 32 ro 0x00000001 Device Powerdown Status
Register
ITMISCOUT
0x00000EDC 10 wo 0x00000000 Miscellaneous Outputs Register
ITMISCIN
0x00000EE0 7 ro x Miscellaneous Inputs Register
ITTRIGGER
0x00000EE8 1 wo 0x00000000 Trigger Register
ITATBDATA0
0x00000EEC 5 wo 0x00000000 ATB Data 0 Register
ITATBCTR2
0x00000EF0 2 ro x ATB Control 2 Register
ITATBID
0x00000EF4 7 wo 0x00000000 ATB Identification Register
ITATBCTR0
0x00000EF8 10 wo 0x00000000 ATB Control 0 Register
ETMITCTRL
0x00000F00 1 rw 0x00000000 Integration Mode Control
Register
CTSR
0x00000FA0 8 rw 0x000000FF Claim Tag Set Register
CTCR
0x00000FA4 8 rw 0x00000000 Claim Tag Clear Register
LAR
0x00000FB0 32 wo 0x00000000 Lock Access Register
LSR
0x00000FB4 3 ro 0x00000003 Lock Status Register
ASR
0x00000FB8 8 ro x Authentication Status Register
DEVID
0x00000FC8 32 ro 0x00000000 Device ID
DTIR
0x00000FCC 8 ro 0x00000013 Device Type Identifier Register
PERIPHID4
0x00000FD0 8 ro 0x00000004 Peripheral ID4
PERIPHID5
0x00000FD4 8 ro 0x00000000 Peripheral ID5
PERIPHID6
0x00000FD8 8 ro 0x00000000 Peripheral ID6
PERIPHID7
0x00000FDC 8 ro 0x00000000 Peripheral ID7
PERIPHID0
0x00000FE0 8 ro 0x00000050 Peripheral ID0
PERIPHID1
0x00000FE4 8 ro 0x000000B9 Peripheral ID1
Register Name Address Width Type Reset Value Description
