Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 958
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (ptm) ETMTRIGGER
Register ETMTRIGGER Details
Register (ptm) ETMSR
NumExtIn 19:17 ro 0x4 Specifies the number of external inputs, four.
Sequencer 16 ro 0x1 Indicates that the sequencer is present.
NumCounters 15:13 ro 0x2 Specifies the number of counters, two.
reserved 12:4 ro 0x0 Reserved
NumAddrComp 3:0 ro 0x4 Specifies the number of address comparator pairs,
four.
Name ETMTRIGGER
Relative Address 0x00000008
Absolute Address debug_cpu_ptm0: 0xF889C008
debug_cpu_ptm1: 0xF889D008
Width 17 bits
Access Type rw
Reset Value 0x00000000
Description Trigger Event Register
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
TrigEvent 16:0 rw 0x0 Trigger event. Subdivided as:
Function, bits [16:14]
Specifies the function that combines the two
resources that define the event.
Resource B, bits [13:7] and Resource A, bits [6:0]
Specify the two resources that are combined by
the logical operation specified by the Function
field.
Name ETMSR
Relative Address 0x00000010
Absolute Address debug_cpu_ptm0: 0xF889C010
debug_cpu_ptm1: 0xF889D010
Width 4 bits
Access Type mixed
Reset Value 0x00000002
