Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 963
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ETMACVR4 Details
Register (ptm) ETMACVR5
Register ETMACVR5 Details
Register (ptm) ETMACVR6
Register ETMACVR6 Details
Access Type rw
Reset Value 0x00000000
Description Address Comparator Value Register 4
Field Name Bits Type Reset Value Description
Address 31:0 rw 0x0 Address for comparison
Name ETMACVR5
Relative Address 0x00000050
Absolute Address debug_cpu_ptm0: 0xF889C050
debug_cpu_ptm1: 0xF889D050
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Address Comparator Value Register 5
Field Name Bits Type Reset Value Description
Address 31:0 rw 0x0 Address for comparison
Name ETMACVR6
Relative Address 0x00000054
Absolute Address debug_cpu_ptm0: 0xF889C054
debug_cpu_ptm1: 0xF889D054
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Address Comparator Value Register 6
Field Name Bits Type Reset Value Description
Address 31:0 rw 0x0 Address for comparison
