Appendix B: Register Details
Register ETMACTR4 Details
Register (ptm) ETMACTR5
Field Name Bits Type Reset Value Description
SecLevelCtrl 11:10 rw 0x0 Security level control
Enumerated Value List:
IGNORE=0.
NONSEC=1.
SECURE=2.
ContextIDCompCtrl 9:8 rw 0x0 Context ID comparator control.
Enumerated Value List:
IGNORE=0.
MATCH1=1.
MATCH2=2.
MATCH3=3.
reserved 7:3 rw 0x0 Reserved
AccessType 2:0 ro 0x1 Access type. Returns the value: Instruction
execute.
Name ETMACTR5
Relative Address 0x00000090
Absolute Address debug_cpu_ptm0: 0xF889C090
debug_cpu_ptm1: 0xF889D090
Width 12 bits
Access Type mixed
Reset Value 0x00000001
Description Address Comparator Access Type Register 5
