Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 972
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ETMACTR8 Details
Register (ptm) ETMCNTRLDVR1
Register ETMCNTRLDVR1 Details
Register (ptm) ETMCNTRLDVR2
Field Name Bits Type Reset Value Description
SecLevelCtrl 11:10 rw 0x0 Security level control
Enumerated Value List:
IGNORE=0.
NONSEC=1.
SECURE=2.
ContextIDCompCtrl 9:8 rw 0x0 Context ID comparator control.
Enumerated Value List:
IGNORE=0.
MATCH1=1.
MATCH2=2.
MATCH3=3.
reserved 7:3 rw 0x0 Reserved
AccessType 2:0 ro 0x1 Access type. Returns the value: Instruction
execute.
Name ETMCNTRLDVR1
Relative Address 0x00000140
Absolute Address debug_cpu_ptm0: 0xF889C140
debug_cpu_ptm1: 0xF889D140
Width 16 bits
Access Type rw
Reset Value 0x00000000
Description Counter Reload Value Register 1
Field Name Bits Type Reset Value Description
InitValue 15:0 rw 0x0 Counter initial value
Name ETMCNTRLDVR2
Relative Address 0x00000144
Absolute Address debug_cpu_ptm0: 0xF889C144
debug_cpu_ptm1: 0xF889D144
