Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 975
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (ptm) ETMCNTRLDEVR2
Register ETMCNTRLDEVR2 Details
Register (ptm) ETMCNTVR1
Register ETMCNTVR1 Details
Name ETMCNTRLDEVR2
Relative Address 0x00000164
Absolute Address debug_cpu_ptm0: 0xF889C164
debug_cpu_ptm1: 0xF889D164
Width 17 bits
Access Type rw
Reset Value 0x00000000
Description Counter Reload Event Register 2
Field Name Bits Type Reset Value Description
CntReloadEvent 16:0 rw 0x0 Count reload event. Subdivided as:
Function, bits [16:14]
Specifies the function that combines the two
resources that define the event.
Resource B, bits [13:7] and Resource A, bits [6:0]
Specify the two resources that are combined by
the logical operation specified by the Function
field.
Name ETMCNTVR1
Relative Address 0x00000170
Absolute Address debug_cpu_ptm0: 0xF889C170
debug_cpu_ptm1: 0xF889D170
Width 16 bits
Access Type rw
Reset Value 0x00000000
Description Counter Value Register 1
Field Name Bits Type Reset Value Description
CurrCount 15:0 rw 0x0 Current counter value.
