Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 977
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (ptm) ETMSQ21EVR
Register ETMSQ21EVR Details
Register (ptm) ETMSQ23EVR
Name ETMSQ21EVR
Relative Address 0x00000184
Absolute Address debug_cpu_ptm0: 0xF889C184
debug_cpu_ptm1: 0xF889D184
Width 17 bits
Access Type rw
Reset Value 0x00000000
Description Sequencer State Transition Event Register 21
Field Name Bits Type Reset Value Description
TransEvent 16:0 rw 0x0 A Sequencer State Transition Event Register,
ETMSQmnEVR, defines the evnet that causes the
sequencer state transition from state m to state n.
The format is subdivided as:
Function, bits [16:14]
Specifies the function that combines the two
resources that define the event.
Resource B, bits [13:7] and Resource A, bits [6:0]
Specify the two resources that are combined by
the logical operation specified by the Function
field.
Name ETMSQ23EVR
Relative Address 0x00000188
Absolute Address debug_cpu_ptm0: 0xF889C188
debug_cpu_ptm1: 0xF889D188
Width 17 bits
Access Type rw
Reset Value 0x00000000
Description Sequencer State Transition Event Register 23
