Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 982
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ETMCIDCVR1 Details
Register (ptm) ETMCIDCMR
Register ETMCIDCMR Details
Register (ptm) ETMSYNCFR
Access Type rw
Reset Value 0x00000000
Description Context ID Comparator Value Register
Field Name Bits Type Reset Value Description
ContextID 31:0 rw 0x0 Holds a 32-bit Context ID value
Name ETMCIDCMR
Relative Address 0x000001BC
Absolute Address debug_cpu_ptm0: 0xF889C1BC
debug_cpu_ptm1: 0xF889D1BC
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Context ID Comparator Mask Register
Field Name Bits Type Reset Value Description
ContextMask 31:0 rw 0x0 Holds a 32-bit Context ID mask
Name ETMSYNCFR
Relative Address 0x000001E0
Absolute Address debug_cpu_ptm0: 0xF889C1E0
debug_cpu_ptm1: 0xF889D1E0
Width 12 bits
Access Type mixed
Reset Value 0x00000400
Description Synchronization Frequency Register
