Appendix B: Register Details
Register OSLSR Details
Register (ptm) ETMPDSR
Register ETMPDSR Details
Register (ptm) ITMISCOUT
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description OS Lock Status Register
Field Name Bits Type Reset Value Description
31:0 ro 0x0 Shows that OS Locking is not implemented.
Name ETMPDSR
Relative Address 0x00000314
Absolute Address debug_cpu_ptm0: 0xF889C314
debug_cpu_ptm1: 0xF889D314
Width 32 bits
Access Type ro
Reset Value 0x00000001
Description Device Powerdown Status Register
Field Name Bits Type Reset Value Description
31:0 ro 0x1 Indicates that the PTM Trace Registers can be
accessed.
Name ITMISCOUT
Relative Address 0x00000EDC
Absolute Address debug_cpu_ptm0: 0xF889CEDC
debug_cpu_ptm1: 0xF889DEDC
Width 10 bits
Access Type wo
Reset Value 0x00000000
Description Miscellaneous Outputs Register
