Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 992
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register CTSR Details
Register (ptm) CTCR
Register CTCR Details
Register (ptm) LAR
Field Name Bits Type Reset Value Description
7:0 rw 0xFF The claim tag register is used for any
interrogating tools to determine if the device is
being programmed or has been programmed.
Read:
1= Claim tag is implemented, 0 = Claim tag is not
implemented
Write:
1= Set claim tag bit, 0= No effect
Name CTCR
Relative Address 0x00000FA4
Absolute Address debug_cpu_ptm0: 0xF889CFA4
debug_cpu_ptm1: 0xF889DFA4
Width 8 bits
Access Type rw
Reset Value 0x00000000
Description Claim Tag Clear Register
Field Name Bits Type Reset Value Description
7:0 rw 0x0 The claim tag register is used for any
interrogating tools to determine if the device is
being programmed or has been programmed.
Read: Current value of claim tag.
Write: 1= Clear claim tag bit, 0= No effect
Name LAR
Relative Address 0x00000FB0
Absolute Address debug_cpu_ptm0: 0xF889CFB0
debug_cpu_ptm1: 0xF889DFB0
Width 32 bits
Access Type wo
Reset Value 0x00000000
