Appendix B: Register Details
Register LSR Details
Register (ptm) ASR
Register ASR Details
Field Name Bits Type Reset Value Description
8BIT 2 ro 0x0 Set to 0 since PTM implements a 32-bit lock access
register
STATUS 1 ro 0x1 Read behavior depends on PADDRDBG31 pin:
- PADDRDBG31=0 (lower 2GB):
When a lower 2GB address is used to read this
register, this bit indicates whether PTM is in
locked state
(1= locked, 0= unlocked).
- PADDRDBG31=1 (upper 2GB):
always returns 0.
IMP 0 ro 0x1 Read behavior depends on PADDRDBG31 pin:
- PADDRDBG31=0 (lower 2GB):
always returns 1, meaning lock mechanism are
implemented.
- PADDRDBG31=1 (upper 2GB):
always returns 0, meaning lock mechanism is
NOT implemented.
Name ASR
Relative Address 0x00000FB8
Absolute Address debug_cpu_ptm0: 0xF889CFB8
debug_cpu_ptm1: 0xF889DFB8
Width 8 bits
Access Type ro
Reset Value x
Description Authentication Status Register
Field Name Bits Type Reset Value Description
SNI 7:6 ro 0x0 Secure non-invasive debug
Always 2'b00,.
This functionality is not implemented
SI 5:4 ro 0x0 Secure invasive debug
Always 2'b00.
This functionality is not implemented.
