Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 997
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (ptm) PERIPHID6
Register PERIPHID6 Details
Register (ptm) PERIPHID7
Register PERIPHID7 Details
Register (ptm) PERIPHID0
Name PERIPHID6
Relative Address 0x00000FD8
Absolute Address debug_cpu_ptm0: 0xF889CFD8
debug_cpu_ptm1: 0xF889DFD8
Width 8 bits
Access Type ro
Reset Value 0x00000000
Description Peripheral ID6
Field Name Bits Type Reset Value Description
7:0 ro 0x0 reserved
Name PERIPHID7
Relative Address 0x00000FDC
Absolute Address debug_cpu_ptm0: 0xF889CFDC
debug_cpu_ptm1: 0xF889DFDC
Width 8 bits
Access Type ro
Reset Value 0x00000000
Description Peripheral ID7
Field Name Bits Type Reset Value Description
7:0 ro 0x0 reserved
Name PERIPHID0
Relative Address 0x00000FE0
Absolute Address debug_cpu_ptm0: 0xF889CFE0
debug_cpu_ptm1: 0xF889DFE0
Width 8 bits
