Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 998
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register PERIPHID0 Details
Register (ptm) PERIPHID1
Register PERIPHID1 Details
Register (ptm) PERIPHID2
Access Type ro
Reset Value 0x00000050
Description Peripheral ID0
Field Name Bits Type Reset Value Description
7:0 ro 0x50 PartNumber0
Name PERIPHID1
Relative Address 0x00000FE4
Absolute Address debug_cpu_ptm0: 0xF889CFE4
debug_cpu_ptm1: 0xF889DFE4
Width 8 bits
Access Type ro
Reset Value 0x000000B9
Description Peripheral ID1
Field Name Bits Type Reset Value Description
JEP106ID 7:4 ro 0xB JEP106 Identity Code [3:0]
PartNumber1 3:0 ro 0x9 PartNumber1
Name PERIPHID2
Relative Address 0x00000FE8
Absolute Address debug_cpu_ptm0: 0xF889CFE8
debug_cpu_ptm1: 0xF889DFE8
Width 8 bits
Access Type ro
Reset Value 0x0000001B
Description Peripheral ID2
