Appendix B: Register Details
Register PERIPHID2 Details
Register (ptm) PERIPHID3
Register PERIPHID3 Details
Register (ptm) COMPID0
Register COMPID0 Details
Field Name Bits Type Reset Value Description
RevNum 7:4 ro 0x1 Revision number of Peripheral
JEDEC 3 ro 0x1 Indicates that a JEDEC assigned value is used
JEP106ID 2:0 ro 0x3 JEP106 Identity Code [6:4]
Name PERIPHID3
Relative Address 0x00000FEC
Absolute Address debug_cpu_ptm0: 0xF889CFEC
debug_cpu_ptm1: 0xF889DFEC
Width 8 bits
Access Type ro
Reset Value 0x00000000
Description Peripheral ID3
Field Name Bits Type Reset Value Description
RevAnd 7:4 ro 0x0 RevAnd, at top level
CustMod 3:0 ro 0x0 Customer Modified
Name COMPID0
Relative Address 0x00000FF0
Absolute Address debug_cpu_ptm0: 0xF889CFF0
debug_cpu_ptm1: 0xF889DFF0
Width 8 bits
Access Type ro
Reset Value 0x0000000D
Description Component ID0
Field Name Bits Type Reset Value Description
7:0 ro 0xD Preamble
