The Pcam 5C PCB was designed to allow for the incorporation of circuitry that can drive an auto-focus M12 liquid lens assembly, such as
those created by Varioptic (http://www.varioptic.com/products/auto-focus-lens-modules/). The circuitry needed to drive a liquid lens
assembly is not loaded in the current version of the Pcam 5C (see page 2 of the Pcam 5C Schematic
(https://reference.digilentinc.com/_media/reference/add-ons/pcam-5c/pcam_5c_sch.pdf)), however this functionality may be incorporated into a
future version of the Pcam 5C. If you are interested in obtaining a liquid lens capable version of the Pcam 5C, please contact Digilent using
the Digilent Forum (https://forum.digilentinc.com/topic/8844-pcam-5c-liquid-lens/).
The schematics of the Pcam 5C are available here (https://reference.digilentinc.com/_media/reference/add-ons/pcam-5c/pcam_5c_sch.pdf).
Additional information about the OV5640 image sensor SoC can be found in the sensor datasheet, which can be obtained by contacting
OmniVision. A brief overview of the OV5640 is publicly available in the OV5640 Product Brief
(https://reference.digilentinc.com/_media/reference/add-ons/pcam-5c/ov5640_product_brief.pdf).
Example code demonstrating how to use the Pcam 5C can be found on its Resource Center (https://reference.digilentinc.com/reference/add-
ons/pcam-5c/start).
If you have any questions or comments about the Pcam 5C, feel free to post them under the appropriate section (“Add-on Boards”) of the
Digilent Forum (https://forum.digilentinc.com/).
