Data Sheet

2/17/2018 Pcam 5C Reference Manual [Reference.Digilentinc]
https://reference.digilentinc.com/reference/add-ons/pcam-5c/reference-manual 5/11
Not yet available for download
5MP color system-on-chip image sensor
15-pin FFC connector for image data
Dual lane MIPI CSI-2 image sensor interface
Supports QSXGA@15Hz, 1080p@30Hz, 720p@60Hz, VGA@90Hz and QVGA@120Hz*
Output formats include RAW10, RGB565, CCIR656, YUV422/420, YCbCr422, and JPEG compression*
Standard M12 lens mount for lens interchangeability
Ships with 10 cm cable and factory installed fixed-focus lens
Small PCB size for flexible designs (4.0 cm x 2.5 cm)
1×7 straight 100-mil header for access to auxiliary camera signals
Works with Pcam compatible Digilent development boards
*Not all resolutions and output formats tested. See “Software Support” section for information on supported modes
Download This Reference Manual
Features
Software Support
