3.1 Zynq EPP Bank Voltages

Table 21 - Zynq Bank Voltage Assignments

EPP PS-Side

Bank

Voltage (default)

MIO Bank 0/500

3.3V

MIO Bank 1/501

1.8V

DDR

1.5V

EPP PL-Side

Bank0

3.3V

Bank 13

3.3V

Bank 33

3.3V

Bank 34

Vadj (2.5V)

Bank 35

Vadj (2.5V)

Note: Banks 34 and 35 are powered from an adjustable voltage rail. Jumper, J18, selects this

voltage. Selectable voltages include 1.8V, 2.5V and 3.3V. The 3.3V jumper was intentionally

unpopulated on ZedBoard as these banks primarily connect to the FMC interface and many FMC

cards are only 1.8V and 2.5V compatible. Connecting 3.3V to these cards can damage them, so

leaving this jumper unpopulated reduces the risk of damaging FMC cards.
