Digital Monitoring Products, Inc. 1912XR Programming
Page 16
OUTPUT OPTIONS
BELL CUTOFF: 15
BELL TST NO
BELL ACTION . . . . .
SUPRVSRY TYPE: N
BURGLARY TYPE: S
PANIC TYPE: N
8.1 OUTPUT OPTIONS - This function allows you to program the panel's Bell Output
functions and certain Relay Output options. Dry contact relays and voltage
outputs are available using the output harness on the 1912XR board. Refer to
the 1912XR Installation Guide (LT-0169) for complete information.
A description of each output option follows:
8.2 BELL CUTOFF TIME - Enter the maximum time the Bell Output remains on. If
the Bell Output is manually silenced or the area is armed or disarmed, the cutoff
time is reset. The Bell Cutoff Time can be from 1 to 99 minutes. Enter zero to
provide continuous bell output.
8.3 AUTOMATIC BELL TEST - When YES is selected, the Bell Output is turned on
for two seconds each time a partition is completely armed.
8.4 BELL ACTION defines the type of Bell Output for loop alarms. Trouble conditions
do not activate the Bell Output. There are seven loop types you can program
individually for Bell Output.
To provide a steady Bell Output, enter S. For a pulsed output, enter P. For no
Bell Output, enter N.
Below is a list of the bell action for seven of the loop types:
8.4A Defines Bell Action for Fire Type Loops
8.4B Defines Bell Action for Burglary Type Loops. If N is selected, Exit Error is not
indicated locally but the Exit Error report will still be sent to the central station.
8.4C Defines Bell Action for Supervisory Type Loops
8.4D Defines Bell Action for Panic Type Loops
8.4E Defines Bell Action for Emergency Type Loops
8.4F Defines Bell Action for Auxiliary 1 Type Loops
8.4G Defines Bell Action for Auxiliary 2 Type Loops
8.5 This option allows you to define the operation of the 1912XR relay outputs. The
panel provides two Form C relays (1 and 2) and four 12 VDC voltage outputs (3
to 6) rated at 50mA each. You can expand the system with up to 100 additional
relay outputs using multiple 716 Output Expander Modules.
8.5A CUTOFF OUTPUT - Outputs 1 to 6 can be entered here to turn off after a time
specified in CUTOFF TIME. See section 8.5B. To disable this option, press any
SELECT key to clear the display of output numbers and then press COMMAND.
The Cutoff Output displays NONE when no outputs are selected.
8.5B OUTPUT CUTOFF TIME - If a Cutoff Output is assigned in section 8.5A, you can
enter a Cutoff Time of up to 99 minutes for the output to remain on. If the output
is turned off, the cutoff time is reset. The Cutoff Time can be from 1 to 99
minutes. Enter zero to provide continuous output.
EMERGNCY TYPE: N
AUXLRY I TYPE: N
AUXLRY 2 TYPE: N
FIRE TYPE: P
CO OUTS: - - - - - -
CUTOFF TIME: 0
OUTPUT ACTION . . .
8-OUTPUT OPTIONS
