Installation manual

Duet2 D2600 / Duet3 D2650 Installation Manual – EU-D2600-D2650-INST/A10/v1 - 4

2. Part Numbers
D2600-B GPRS Duet2 (including aerial)
D2650 Duet3 (including aerial)
D1501-B Tamper protected box with 1-amp power supply
D2454 Downloading software and NVM programmer
D2355 LAN card
D0730 Security ADSL (Broadband) filter
D0402 Products CD with manuals for all products
CS0355 NVM programming socket (USB)
Fig 1 - D2600-B Duet2
A2 and B2
panel
connections

SIM card socket
Aerial connector
GSM and signal
strength LEDs
Communication
and path status

LEDs
Reset and test
pins

NVM in socket
4 inputs
4 outputs
Fault
relay
terminals
12v power
connections

LAN card
slot

A1 and B1
telephone
connections

A and B PSTN
connections
