5.4.18 Power Supply (P/N 29-28461-01)
To remove the power supply, refer to Figure 5–21 and proceed as follows:
1. Disconnect the connector J1 and J2 from the power supply .
2. Remove the two nuts and nut plate attaching the power supply to the side of the
chassis.
3. Remove the two nuts attaching the power supply to the bottom of the chassis.
4. Lift the rear of the power supply just enough to clear the standoffs and then lift the front
of the supply and carefully maneuver it out of the drive.
To replace the power supply, follow the removal procedure in reverse order.
