5.4.29 Supply Motor (P/N 29-28470-01)
To remove the supply motor, refer to Figure 5–31 and proceed as follows:
1. Remove the supply hub (refer to Section 5.4.27).
2. Remove the clip securing the supply hub bell crank to the supply motor .
3. Disconnect the two connectors ( and ) from the motor.
4. Loosen the four screws securing the supply motor to the deck plate.
5. Hold the motor while removing the four screws .
6. When removing the motor from the deck plate, slide the supply hub bell crank off the
stud on the motor.
To replace the motor, proceed as follows:
1. Perform the removal procedure in reverse order.
2. Perform the Supply Hub Adjustment (Section 6.4).
5–48 Removal/Replacement Procedures
