5.4.30 Take-Up Hub
To remove the take-up hub, refer to Figure 5–32 and proceed as follows:
1. Secure the packer arm away from the take-up hub using tape or string.
2. Loosen the two screws that secure the take-up hub to the take-up motor shaft, then
remove the take-up hub.
To replace the take-up hub, proceed as follows:
1. Install the take-up hub on the take-up motor shaft. Do not tighten the two screws .
2. Perform the Take-Up Hub Adjustment (refer to Section 6.5).
5–50 Removal/Replacement Procedures
