Table 4–6: Service Aid 111 Switch Functions

Switch Function During Test

1 Causes supply motor to rotate clockwise (MAN SPLY test) or the take-up motor to rotate

counterclockwise (MAN TKUP).

2 Causes the take-up motor to rotate clockwise (MAN TKUP test) or the supply motor to

rotate counterclockwise (MAN SPLY) test.

3 Reverses motor direction.

4 Exits the service aid.

5 Exits any test and returns to the MODE ? prompt.

At the MODE? prompt, the oscillation test (Auto OSC), the supply motor test (MAN SPLY), or

the take-up motor test (MAN TKUP) may be selected by pressing switch 1, 2 or 3, respectively.

After selecting the test, switch 5 must be pressed to start the test.

The auto oscillation test (AUTO OSC) cycles the take-up and supply motors in alternate

directions. The supply motor test (MAN SPLY) and the take-up motor test (MAN TKUP)

operate their respective motors in either the clockwise or counterclockwise direction. The

initial motor speed is zero. By pressing continuously on either switch 1 or 2, the speed

increases to the maximum capability of the motor in the direction speciﬁed in Table 4–6.

Pressing continuously on the other switch (2 if 1 was pressed initially, or vice versa) decreases

the speed to zero, reverses direction, then increases the speed to maximum in the new

direction.

4.5.2.2 Service Aid 125 (Firmware ID)

Service Aid 125 displays the revision levels of the ﬁrmware for the Z8002 and 80188

microprocessors and the type of interface. Three messages are displayed during this service

aid:

NOTE

This service aid is used when a tape is not loaded. Service Aid 225 may be

used when a tape is loaded.

1. DEV REV for the Z8002 revision level

2. I/F REV for the 80188 revision level

3. I/F TYPE for the type of interface

During this service aid the front panel switches function as described in Table 4–7.

Troubleshooting 4–11
