5.4.5 EOT/BOT Sensor Assembly (P/N 29-28649-01)
To remove the EOT/BOT Sensor Assembly, see Figure 5–8 and proceed as follows:
1. Remove the two screws and washers securing the EOT/BOT Sensor Assembly to the
deck plate, then remove the assembly.
2. Disconnect the connector from the EOT/BOT Sensor Assembly.
To replace the sensors, follow the removal procedure in the reverse order. Use Service Aid
132 (Section 4.5.2.4) to verify that both sensors function properly.
Figure 5–8: Removing the EOT/BOT Sensor Assembly
