5.4.10 Hub Lock Solenoid (P/N 29-28475-01)
To remove the hub lock solenoid, see Figure 5–13 and proceed as follows:
1. Disconnect the connector from the hub lock solenoid .
2. Remove the two screws attaching the solenoid to the deck plate, then remove the
solenoid.
To replace the hub lock solenoid, follow the removal procedure in the reverse order. However,
make sure the bell crank plunger is inserted through the spring and into the solenoid
. Verify that the hub lock functions properly using Service Aid 132 Section 4.5.2.4.
5–22 Removal/Replacement Procedures
