5.4.14 Left Output Air Duct
To remove the left output air duct, see Figure 5–17 and proceed as follows:
1. Remove the screw attaching the air duct to the deck plate.
2. Disconnect the air duct from the nozzle .
To replace the left output air duct, follow the removal procedure in reverse order.
Figure 5–17: Removing the Left Output Air Duct
Removal/Replacement Procedures 5–29
