PRACTICAL USER’S GUIDE FOR THE CORNER STANDING STOVE Serial Number _________________ Model Number _________________ CAT Number __________________ Quality checked by: Valued Customer, We are pleased that you have chosen to purchase an electric fireplace manufactured by Dimplex North America Limited.
CONTENTS PAGE 1 Important Instructions PAGE 2 Model and Serial Number Information PAGE 3 Securing Cord Stabilizing Strap PAGE 4 Operation PAGE 5 Remote PAGE 6 Maintenance PAGE 8 Warranty
QUICK REFERENCE GUIDE FOR THE CORNER STANDING STOVE 1. Before using the electric corner wall mounted fireplace verify: • Are the circuit breakers for the unit on? • Are the light bulbs loose? (to check, follow the instructions for replacing the light bulbs under the maintenance section of this manual) 2. The heater may emit a slight, harmless odor when first used. This odor is a normal condition caused by the initial heating of internal heater parts. 3.
IMPORTANT INSTRUCTIONS SAVE THESE INSTRUCTIONS RETAIN THIS USER’S GUIDE FOR FUTURE REFERENCE When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons. 1. Read all instructions before using the corner wall mounted electric fireplace. 2. The heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. The trim around the heater outlet becomes hot during heater operation.
IMPORTANT INSTRUCTIONS If you have any questions about out products please have the product model and serial numbers available upon calling Dimplex customer service. To locate the model and serial number labels see below. Record the Model Number, Serial Number, and CAT number on the front cover of this manual for future reference.
NOTE A 15amp, 120 volt circuit is required. A dedicated circuit is preferred but not essential in all cases. A dedicated circuit will be required if, after installation, the circuit breaker trips or the fuse blows on a regular basis when the heater is operating. Additional appliances on the same circuit may exceed the current rating of the circuit breaker.
SUPPORT HOLE FIGURE 12 WALL ANCHOR 1/8” HOLE IN WALL BOLT SAFETY STRAP FIGURE 13 SAFETY STRAP FIGURE 14 4
OPERATION – EMSC-W, EMSC-ESP, DCF7850W, DCF7850E The controls are located inside the door panel on the lower side of the corner wall mounted electric fireplace. (FIGURE 15) EWMSC-W EWMSC-ESP DCF7850W DCF7850E A. MAIN ON/OFF SWITCH The switch has two ON positions marked with and “Manual”. The “Manual“ position is for manual operation. In this position the built-in remote control is bypassed. The When in position is for operating the unit with the provided remote control.
RESETTING THE TEMPERATURE CUTOFF SWITCH Should the heater overheat, an automatic cut out will turn the heater off and it will not come back on without being reset. It can be reset by switching the MAIN ON/OFF SWITCH to OFF and waiting 5 minutes before switching the unit back on. CAUTION If you need to continuously reset the heater, unplug the unit and call Dimplex technical support at 1-888-DIMPLEX (1-888-346-7539) Extension 4. NOTE The heater may emit a slight, harmless odor when first used.
MAINTENANCE WARNING Disconnect power before attempting any maintenance or cleaning to reduce the risk of fire, electric shock or damage to persons. LIGHT BULB REPLACEMENT Allow at least 5 minutes for light bulbs to cool before touching bulbs to avoid accidental burning of skin. Light bulbs need to be replaced when you notice a dark section of the flame or when the clarity and detail of the log exterior disappears. There are two bulbs under the log set which generate the flames and embers.
GLASS CLEANING The front glass is cleaned in the factory during the assembly operation. During shipment, installation, handling, etc., the front glass may collect dust particles, these can be removed by dusting lightly with a clean dry cloth. To remove fingerprints or other marks, the glass can be cleaned with a damp cloth. The glass should be completely dried with a lint free cloth to prevent water spots. To prevent scratching, do not use abrasive cleaners or spray liquids on the glass surface.
TWO YEAR LIMITED WARRANTY Products to which this limited warranty applies This limited warranty applies to the following models of your newly purchased Dimplex Corner Standing Electric Stove. This limited warranty applies only to purchases made in any province of Canada except for Yukon Territory, Nunavut, or Northwest Territories or in any of the 50 States of the USA (and the District of Columbia) except for Hawaii and Alaska.
What Dimplex will do in the event of a defect In the event a product or part covered by this limited warranty is proven to be defective in material or workmanship during (i) the 2 year limited warranty period for products other than fireplace surrounds (mantels) and trims, and (ii) the 1 year limited warranty period for surrounds (mantels) and trims, you have the following rights: Dimplex will in its sole discretion either repair or replace such defective product or part without charge.
How State and Provincial law apply This limited warranty gives you specific legal rights, and you may also have other rights which vary from jurisdiction to jurisdiction. The provisions of the United Nations Convention on Contracts for the Sale of Goods shall not apply to this limited warranty or the sale of products covered by this limited warranty.
